MEDIAL LUXATING PATELLA

 decorative bar

The medial luxating patella, commonly called “trick knee,” is an extremely common problem in toy breed dogs. An owner typically notices a little skip in the dog’s step. The dog may even run on three legs, holding one hind leg up, and then miraculously be back on four legs as if nothing has happened.

In fact, something has happened: the kneecap (or “patella”) has slipped out of the smooth groove in which it normally rides up and down. It has slipped “medially” which is to say towards the opposite leg, as opposed to “laterally” which would be away from the dog entirely. With the patella dislocated (or “luxated”) medially, the knee cannot extend properly and stays bent. With luck, the patient will be able to slip the kneecap back where it belongs and be back to normal in only a few steps.On the other hand, for some dogs, a kneecap back where it belongs and normal extension of the rear leg is a mere dream only attainable with surgical correction.
Media Luxating Patella xray

X-ray of a dog with
a medial luxating patella (on left side)
and a normal knee (right side)
(original graphic by marvistavet.com)

normal knee

Closer view of normal knee. Patella (inside yellow circle) is centered over groove (under patella, pointed to
by yellow arrow)
(original graphic by marvistavet.com)

Approximately 50% of affected dogs have both knees involved while the other 50% has only one knee involved.



WHICH DOGS NEED CORRECTION?

Medial patellar luxations are graded to assess severity.

Grade I:  The kneecap can be moved out of place manually but will fall back into its natural position once the manipulator lets go. Treatment for this form, is rarely needed.

Grade 2:  The kneecap occasionally slips out of its groove spontaneously creating an intermittent lameness. The kneecap will go back in place on its own. Whether or not it needs surgery depends on several factors: how often lameness is a problem, how long lameness lasts when it is a problem. Another reason to proceed with surgical intervention is for prevention. If the ridge of bone on the inside of the knee wears down, the Grade 2 will progress to Grade 3. This progression can be prevented with surgery.

Grade 3:  The patella is out of place all the time but can be manipulated back into its normal position manually (though it will not stay there). At this point, the dog may seem to crouch or slant down in the rear. Lameness or rear weakness may be persistent. A bow-legged appearance may be present. These patients ought to have knee surgery to correct these problems.

Grade 4:  The patella is out of place all the time and no amount of manipulation can return it to its proper place. Such a dog has extreme difficulty extending his knees and walks with his knees bent virtually all the time in a somewhat crouched position. In this situation, the rotation in the long bones that accompanies the luxation will interfere with surgical correction and total resolution of the lameness may not be possible. Surgery is definitely in order, though, success is somewhat variable as this is a very advanced situation.

decorative bar

It is not a good thing to have one’s knee cap out of place; the entire weight-bearing stress of the rear leg is altered which, in time, leads to changes in the hips, long bones, and ultimately arthritis. How severe the changes are depend on how severe the luxation is (i.e. the grade as described above) and how long that degree of luxation has been going on. In time, the legs will actually turn outward with its muscles turning inward, making the dog “bow-legged.” The luxation is not considered a painful condition but after enough time and conformational change, arthritis sets in, which is indeed painful.

  • Dogs with Grade I luxations do not require surgical repair.

  • Often they can be managed with weight control and periodic anti-inflammatory medications.

  • Grade 2 dogs may benefit from surgery and most often the owner is called upon to judge how big a problem the lameness is.

  • Dogs with Grade 3 or 4 disease definitely should have surgery.

This type of surgery is often referred to a surgical specialist, though if your regular veterinarian is well experienced, the surgery can be done at your regular hospital. If referral is needed, your veterinarian will make a recommendation or you can visit www.acvs.org to locate a veterinary surgeon near you.



WHAT SURGICAL PROCEDURES ARE AVAILABLE?

LATERAL IMBRICATION (ALSO CALLED LATERAL REINFORCEMENT)

This procedure alone may be adequate for a mild case but is often used as an adjunctive procedure to supplement one of the other surgeries. When the patella slips out of its groove, the joint capsule surrounding it is stretched to allow this motion. Imbrication simply involves taking a tuck in the joint capsule. The tightened joint capsule does not allow for the slipping of the kneecap and the kneecap is confined to its proper groove.

TROCHLEAR MODIFICATION

The patella rides in a groove at the bottom of the femur (thigh bone). In toy breed dogs this groove is shallow which allows the patella to slip. If the groove is deepened, the patella stays where it belongs. The normal groove in the femur is lined by slippery lubricated cartilage, called “hyaline cartilage”. This cartilage is peeled or cut away, the bone underneath is sliced out to form a deeper groove, and the cartilage is replaced. Techniques that do not preserve the original cartilage are no longer recommended.

TRANSPOSITION OF THE TIBIAL TUBEROSITY

If the knock-kneed conformation has already started to set in, the tibias (or leg bones) will have rotated. In particular, the tibial crest, which we all know as the shin bone, will have rotated inward. The tibial crest includes the tibial tuberosity, a bump on the crest where the thigh muscle attaches. If all this bone rotation has occurred, the crest will need to be broken and the tibial tuberosity chipped off and pinned to a new location so the leg can be straightened out. Severe rotation of the tibias may involve actually cutting through the entire bone and de-rotating it back into place.

THE RIDGESTOP® IMPLANT (NEW)

The Ridgestop implant is a small curved plate that essentially adds height to the ridge of bone on the inside of the knee. By making this area larger, the knee cap becomes unable to slip over it. This technique can be used as a sole solution for Grade 2 laxations or as an adjunct to the other surgical repairs.



SHOULD BOTH KNEES BE REPAIRED AT ONCE OR SHOULD THEY BE STAGED?

Some surgeons feel that doing one leg at a time, 8 weeks or more apart, is beneficial as the patient will have one good rear leg upon which to walk. If the patient is very young (under age one year) it may be a good idea to do both legs at the same time so as to prevent conformational problems in the leg not operated on first. Every surgeon will have their own philosophy on whether or not to do both legs at once. Consult your surgeon about pros and cons and decide.



POST-OPERATIVE CARE

If imbrication was the only procedure, expect three to four weeks of confinement to a large crate or pen, during which the pet will need to be carried outside for bathroom functions. If any of the other procedures above were utilized, expect more like 6-8 weeks of confinement depending on the surgeon’s preference. During this time easy walking (no running or jumping) is helpful. The dog should be using the leg by two weeks post-operatively though some dogs must be retrained to use the leg after surgery. Physical therapy is in order if the dog is not using the leg after one month.

decorative bar

ACVS Logo

The American College of Veterinary Surgeons has included Patellar Luxation in their own web site medical library. Their page can be viewed at:

www.acvs.org/small-animal/patellar-luxations
